A bench drill is an indispensable tool for both DIY enthusiasts and professional craftsmen who want precise holes in wood, metal or plastic. The machine offers stability, consistency and control, which are hard to achieve with a portable drill. However, the market offers many models with different features, sizes and price ranges, and choosing the most suitable one for your needs can be difficult.
In this article, you will get an overview of the most important aspects to consider before buying a bench drill, as well as an introduction to the different types and manufacturers on the market.
The article presents a wide range of bench drills from different price ranges and with various features. The aim is to provide an informative overview of the most relevant characteristics so that you can more easily evaluate which type of machine suits your projects. The product information is based on publicly available descriptions from manufacturers and retailers, summarised to provide a clear and neutral picture.
Factors to consider when buying a bench drill
When choosing a bench drill, you should consider the machine’s capacity, precision and ease of use. Here are some of the most important factors that can help you make the right choice.
1. Drilling capacity and motor power
The drilling capacity indicates the size of the holes the machine can make, while the motor power determines how efficiently it can work in hard materials. For hobby use, a machine with 350–500 watts is often sufficient, while professional tasks require more powerful models of 700 watts or more.
2. Drilling speed and adjustment
Most bench drills have several speed settings, allowing you to adjust the rotation speed according to the material. High speed is suitable for wood, while lower speed offers better control in metal. A machine with continuous speed adjustment provides the greatest flexibility.
3. Table and adjustment options
A stable and adjustable drilling table makes work more precise. Check whether the table can tilt and be adjusted in height so that you can drill at different angles and material thicknesses. An integrated depth stop function is also useful for repetitive drilling tasks.
4. Noise and vibrations
A good bench drill should run smoothly and without too many vibrations. This provides both better precision and a more comfortable working experience. Machines with cast steel construction and a solid base effectively reduce vibrations.
5. Safety and ease of use
Safety should always be a priority. Choose a model with a protective screen, emergency stop and good lighting of the work area. An easy-to-use machine with accessible controls and clear scales makes work faster and safer.
6. Price and quality
The price depends on the size of the machine, motor power and additional features. Cheaper models cover most hobby needs, while more expensive machines usually offer better precision, longer lifespan and more advanced adjustment options. Consider how often you will use the machine and choose accordingly.
Products in focus
The JET 210 Z Bench Drill is a compact and stable machine designed for precision drilling in various materials. It comes with a keyed chuck (0.5–13 mm) and a 75 mm vice, ready for use straight out of the box.
The machine is equipped with a safety device combined with the chuck drive and an emergency stop button located at the front for increased safety during operation. Speed changes are made via belt transmission, allowing adjustment of drilling speed according to the material.
The drill table has two parallel 12 mm slots, and the spindle can travel 53 mm in stroke length. With a B16 spindle taper and a maximum drilling diameter of 10 mm, the machine is suitable for precision work on smaller parts.
The motor operates at 230V and delivers 0.19 kW. The machine has five speeds, ranging from 600 to 2600 revolutions per minute, providing flexibility for different drilling tasks. Its compact size and weight of 32 kg make it easy to place on a workbench.
The JET 210 Z is built with a focus on reliability and ease of use, making it suitable for both hobby workshops and light professional use.
- Five speeds: Adjustable drilling speed from 600 to 2600 rpm via belt transmission.
- Safe operation: Equipped with emergency stop and chuck safety device.
- Compact design: Fits well on workbenches in smaller workshops.
- Stable construction: The 32 kg weight provides good stability during drilling.
- Ready to use: Includes keyed chuck (0.5–13 mm) and 75 mm vice.
Pros and cons
- Stable and compact construction
- Multiple speed settings via belt transmission
- Integrated emergency stop for increased safety
- Comes with relevant accessories
- Drilling capacity limited to max. 10 mm
- Manual speed adjustment requires belt change
Pros and cons
Pros
- Stable and compact construction
- Multiple speed settings via belt transmission
- Integrated emergency stop for increased safety
- Comes with relevant accessories
Cons
- Drilling capacity limited to max. 10 mm
- Manual speed adjustment requires belt change
Pros
- Stable and compact construction
- Multiple speed settings via belt transmission
- Integrated emergency stop for increased safety
- Comes with relevant accessories
Cons
- Drilling capacity limited to max. 10 mm
- Manual speed adjustment requires belt change
Specifications
- Model: 210 Z
- Manufacturer: JET
- Motor voltage: 230 V
- Motor power: 0.19 kW
- Spindle taper: B16
- Maximum drilling diameter: Ø10 mm
- Working depth: 105 mm
- Spindle travel: 53 mm
- Speeds: 5 steps (600–2600 rpm)
- Drill table: 2 parallel 12 mm slots
- Slots (number/size): T12
- Weight: 32 kg
- Dimensions (L×W×H): 600 × 420 × 240 mm
- Included accessories: Keyed chuck 0.5–13 mm, 75 mm vice
The Axminster Workshop AW315PD is a bench drill made of cast iron and machined steel, providing high stability and reducing vibrations during use. It is equipped with a quiet 550 W induction motor that drives the spindle through a belt system with 12 different speeds, ranging from 210 to 2,580 revolutions per minute.
The machine has a keyless chuck with a capacity from 1 to 16 mm, making it easy to change drill bits without tools. The drilling depth can be precisely adjusted, and the feed handle is fitted with soft grips for better control.
The table height is adjusted via a rack and pinion system, and the entire table can be rotated so that the machine base can be used as a support for larger workpieces. An adjustable safety guard and a front-mounted NVR switch contribute to safe operation.
The AW315PD is suitable for precision drilling in wood, plastic and metals and is a practical choice for users who want a stable and reliable machine for workshop use.
- Cast iron construction: Provides stability and reduces vibrations during drilling.
- 550 W induction motor: Ensures quiet and reliable operation.
- 12 speeds: From 210 to 2,580 rpm for different materials and drilling tasks.
- Keyless chuck: Quick and easy drill bit changes from 1 to 16 mm.
- Adjustable table: Height and angle can be adjusted via the rack and pinion system.
Pros and cons
- Robust cast iron construction that dampens vibrations
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick drill bit changes
- Suitable for precision work in multiple materials
- Not compatible with mortising attachments
- The relatively heavy 37 kg construction may require a fixed position
Pros and cons
Pros
- Robust cast iron construction that dampens vibrations
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick drill bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with mortising attachments
- The relatively heavy 37 kg construction may require a fixed position
Pros
- Robust cast iron construction that dampens vibrations
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick drill bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with mortising attachments
- The relatively heavy 37 kg construction may require a fixed position
Specifications
- Model: AW315PD
- Item number (SKU): AX107691
- Voltage: 230 V
- Power: 550 W
- Speeds: 12 steps (210–2,580 rpm)
- Chuck capacity: 1–16 mm
- Chuck type: Keyless
- Chuck travel: 60 mm
- Column diameter: 60 mm
- Maximum chuck–spindle distance: 430 mm
- Maximum chuck–table distance: 315 mm
- Maximum drilling in mild steel: 16 mm
- Table size: 198 × 198 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 127 mm
- Dimensions (L × W × H): 520 × 260 × 840 mm
- Weight: 37 kg
- Plug type: British 3-pin plug
- User level: Home workshop
The PROMAC Bench Drill 370ELB is a stationary machine designed for precision drilling in metal and other hard materials. The machine is powered by a 230 V motor with an output of 0.75 kW and has a single speed, which is adjusted via a V-belt.
It is equipped with a 16 mm self-tightening chuck, protective screen and emergency stop button for increased safety during use. The worktable has adjustable cross grooves that provide flexibility when securing workpieces, and a safety system prevents automatic restart after a power failure.
An integrated LED work light provides directional illumination of the drilling area, improving accuracy when working on detailed pieces. The machine’s construction and weight of 74 kg contribute to stable operation with minimal vibration.
With a speed range from 290 to 2300 revolutions per minute and a drilling depth of up to 80 mm, the 370ELB is suitable for a wide range of workshop drilling tasks.
- Single-speed motor: Simple and reliable design with V-belt adjustment.
- Self-tightening chuck: Allows quick drill bit changes without using a key.
- Safety features: Protective screen, emergency stop and system against automatic restart.
- LED work light: Provides precise illumination of the drilling area.
- Stable construction: The machine’s weight of 74 kg reduces vibrations during operation.
Pros and cons
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED light for better illumination of the work area
- Safety system against automatic start-up
- Suitable for precision drilling in metal
- Single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires fixed placement on the workbench
Pros and cons
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED light for better illumination of the work area
- Safety system against automatic start-up
- Suitable for precision drilling in metal
Cons
- Single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires fixed placement on the workbench
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED light for better illumination of the work area
- Safety system against automatic start-up
- Suitable for precision drilling in metal
Cons
- Single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires fixed placement on the workbench
Specifications
- Motor voltage: 230 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12 steps
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number / SKU: 370ELB
The Holzmann ZS40HS 400V is a stationary bench drill designed for precision work in metal and wood. It is equipped with an extra-large cast iron worktable that can be adjusted in height and rotated 360 degrees around the central axis. The table has 14 mm T-slots, allowing secure clamping of workpieces and accessories during operation.
The machine’s gear head can be adjusted in height and tilted, providing flexibility when drilling at different angles. The gears are oil-bathed to ensure smooth and quiet operation as well as a long service life. The powerful motor provides continuous drilling power, making the machine suitable for demanding tasks.
For increased safety, the spindle guard is height-adjustable and equipped with a microswitch. The machine comes with a drill chuck (16 mm), reducers (MT4/3 and MT3/2), wedge and extraction rod, so it can be used immediately.
With a maximum height of over two metres and a weight of 320 kg, the ZS40HS 400V is a stable and solid machine built for precision and durability in workshop environments.
- XL worktable: Large cast iron table (550 × 480 mm) with 360° rotation and T-slots.
- Adjustable gear head: Can be tilted and height-adjusted for flexible drilling.
- Oil bath gearbox: Ensures smooth operation and reduced wear.
- Powerful motor: Provides continuous drilling power for demanding tasks.
- Safety feature: Spindle guard with microswitch for increased safety.
Pros and cons
- Solid cast iron construction
- Large working surface with flexible adjustment
- Oil bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
- The heavy weight of 320 kg requires a fixed installation
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros and cons
Pros
- Solid cast iron construction
- Large working surface with flexible adjustment
- Oil bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- The heavy weight of 320 kg requires a fixed installation
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros
- Solid cast iron construction
- Large working surface with flexible adjustment
- Oil bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- The heavy weight of 320 kg requires a fixed installation
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Specifications
- Model: ZS40HS 400V
- Manufacturer: Holzmann
- Motor power (S6/S1): 1500/1100 W
- Voltage: 400 V
- Cable length: 2.5 m
- Table size: 550 × 480 mm
- Maximum height: 2120 mm
- Spindle travel: 120 mm
- Spindle–base distance: 1250 mm
- Maximum spindle–table distance: 790 mm
- Weight: 320 kg
- Included accessories: 16 mm drill chuck, MT4/3 and MT3/2 reducers, wedge, extraction rod
The Scheppach DP16VLS is a stationary bench drill designed for precision drilling in various materials such as metal and wood. The integrated positioning laser helps to accurately mark the drilling point, making the work more efficient and precise.
The machine is powered by a 500 W motor that operates at 230 volts and offers five different speeds, from 600 to 2600 revolutions per minute. This allows the user to adjust the speed according to the material and drilling task.
The drill chuck ranges from 3 to 16 mm, and the maximum drilling size is 16 mm. The worktable measures 160 x 168 mm, and the column diameter is 46 mm, providing stability during drilling. The spindle travel is 46 mm, and the machine has an overall size of 460 x 255 x 630 mm.
Weighing 17 kg, the DP16VLS is light enough to be moved when needed, yet robust enough to remain stable during use. A vice is included as standard, increasing flexibility when securing workpieces.
- Positioning laser: Provides accurate marking of the drilling point.
- Flexible speed control: Five speeds from 600 to 2600 rpm.
- Powerful motor: 500 W motor for various drilling tasks.
- Stable construction: 46 mm column diameter and solid base for safe operation.
- Included vice: Facilitates securing workpieces during drilling.
Pros and cons
- Integrated laser for precise drilling
- Multiple speed settings for different materials
- Compact and stable construction
- Included vice increases usability
- Limited spindle travel of 46 mm can be challenging for deeper drilling
- Not intended for heavy industrial use
Pros and cons
Pros
- Integrated laser for precise drilling
- Multiple speed settings for different materials
- Compact and stable construction
- Included vice increases usability
Cons
- Limited spindle travel of 46 mm can be challenging for deeper drilling
- Not intended for heavy industrial use
Pros
- Integrated laser for precise drilling
- Multiple speed settings for different materials
- Compact and stable construction
- Included vice increases usability
Cons
- Limited spindle travel of 46 mm can be challenging for deeper drilling
- Not intended for heavy industrial use
Specifications
- Motor power: 500 W – 230 V
- Revolutions/min: 1450
- Speeds: 600 / 900 / 1300 / 1800 / 2600 rpm
- Chuck: 3–16 mm
- Maximum drilling size: 16 mm
- Worktable: 160 × 168 mm
- Column diameter: 46 mm
- Spindle travel: 46 mm
- Dimensions (L × W × H): 460 × 255 × 630 mm
- Weight: 17 kg
- Included accessories: Vice
- Item number (SKU): 5906810901
The Optimum OPTIdrill DQ 14 is a bench drill designed for precision drilling in metal and other materials. The machine is made of die-cast aluminium and equipped with soft-grip handles, providing stable and comfortable operation.
The drilling table can tilt ±45° and rotate 360°, offering flexibility for various drilling tasks. A clear depth scale and a separate emergency stop button contribute to safe and controlled operation.
The spindle is equipped with precision bearings and offers a concentricity accuracy of less than 0.03 mm, making the machine suitable for tasks where precision is essential. The quick-action chuck and GATES quality belt ensure efficient power transmission.
With a motor power of 0.35 kW and a speed range from 700 to 2500 revolutions per minute in five steps, the machine can be adapted to different materials and drilling types. The large base plate with T-slots provides stability during operation.
- Precision drilling: Concentricity accuracy below 0.03 mm for high precision.
- Flexible drilling table: Can be tilted ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium with soft-grip handles for stability and comfort.
- Efficient power transmission: Equipped with GATES quality belt and precision bearings.
- Safe operation: Separate emergency stop and 24 V DC safety voltage.
Pros and cons
- High precision and stable operation
- Adjustable and rotatable drilling table
- Robust aluminium construction
- Compact size suitable for workbenches
- Safety features such as emergency stop and low voltage
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros and cons
Pros
- High precision and stable operation
- Adjustable and rotatable drilling table
- Robust aluminium construction
- Compact size suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros
- High precision and stable operation
- Adjustable and rotatable drilling table
- Robust aluminium construction
- Compact size suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Specifications
- Manufacturer: Optimum
- Model: OPTIdrill DQ 14
- SKU: SM-3191040
- Column diameter: 46 mm
- Length: approx. 472 mm
- Width/depth: approx. 283 mm
- Height: approx. 634 mm
- Weight: approx. 18.5 kg
- Drilling capacity in steel (S235JR): 13 mm
- Continuous drilling capacity in steel (S235JR): 12 mm
- Drilling table size: 170 × 170 mm
- T-slot size: 14 mm (2 pcs., diagonal type)
- Drilling table rotation: 360°
- Drilling table angle: ±45°
- Maximum distance spindle – drilling table: 250 mm
- Maximum distance spindle – machine base: 340 mm
- Drive motor power: 0.35 kW
- Supply voltage: 230 V
- Mains frequency: 50 Hz
- Speed range: 700–2500 min⁻¹ (5 steps)
- Spindle travel: 52 mm
- Spindle chuck: B16
- Throat depth: 104 mm
The Proxxon TBH is a bench drill developed for precision work, where stability and accuracy are essential. The machine is powered by a strong and durable DC motor that ensures smooth operation and constant torque under load.
The height is easily adjusted via a rack-and-pinion mechanism and crank handle, providing precise control over the drilling position. The spindle drive is equipped with three pulleys, allowing three speed levels – 1080, 2400 and 4500 revolutions per minute – so the user can adapt the speed to the material.
The machine has a drilling depth scale with adjustable stop, and the drill spindle is mounted in precision bearings to ensure stable operation. The spindle head has a 1/2" thread and fits an industrial-quality RÖHM chuck. In addition, the spindle can be equipped with collars (no. 28200) for additional precision work.
With a column of 45 x 500 mm, a worktable of 200 x 200 mm and a weight of approximately 10 kg, the TBH is both stable and compact, making it suitable for smaller workshops and precision tasks in metal and plastic.
- DC motor: Durable motor with stable operation and low vibration.
- Stepwise speed control: Three speed levels (1080, 2400 and 4500 rpm) for different materials.
- Precise height adjustment: Rack and crank handle for easy and accurate adjustment.
- Stable construction: Column and table with robust design for precision drilling.
- Compatibility: Fits RÖHM chuck and collars no. 28200.
Pros and cons
- Precise and stable operation thanks to spindle bearings
- Long service life due to DC motor
- Easy height adjustment with crank handle
- Possibility to use collars for precision drilling
- Compact and solid construction
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change for speed adjustment
Pros and cons
Pros
- Precise and stable operation thanks to spindle bearings
- Long service life due to DC motor
- Easy height adjustment with crank handle
- Possibility to use collars for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change for speed adjustment
Pros
- Precise and stable operation thanks to spindle bearings
- Long service life due to DC motor
- Easy height adjustment with crank handle
- Possibility to use collars for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change for speed adjustment
Specifications
- Voltage: 220–240 V
- Speeds: 1080 / 2400 / 4500 rpm
- Spindle travel: 63 mm
- Height adjustment: 70 mm via crank handle
- Throat depth: 120 mm
- Table working surface: 200 × 200 mm
- Column: 45 × 500 mm
- Maximum drilling capacity in steel: 10 mm
- Clamping range: up to 10 mm
- Weight: approx. 10 kg
- Compatible chuck: RÖHM chuck (1/2" thread)
- Collar option: no. 28200
- SKU: ROL-28124
The Record DP58B Heavy Duty is a stationary bench drill made of steel and cast iron to ensure stability and long service life. It is equipped with a powerful induction motor that provides smooth operation and can handle both hardwood and metal pieces.
The machine has a cast iron table with grooves that allow secure clamping of a vice. The table can tilt up to 45 degrees, offering flexibility for angled drilling. A rack and pinion system makes height adjustment easy.
With 12 different speeds, the user can adjust the rotation speed according to the material, making the machine suitable for many types of drilling work. The spindle housing is designed to minimise vibrations and ensure precision during operation.
The machine has a maximum chuck capacity of 16 mm, a weight of 55 kg and a total height of 1050 mm, making it suitable for both professional users and hobbyists who want a stable and precise bench drill.
- 12 speeds: Allows precise adjustment for different materials.
- Cast iron table: Can tilt up to 45° and has grooves for securing a vice.
- Induction motor: Provides stable power for drilling in wood and metal.
- Solid construction: Steel and cast iron reduce vibrations and increase precision.
- Ergonomic design: Handles and height adjustment are designed for easy operation.
Pros and cons
- Robust, vibration-damping construction
- Flexible speed control with 12 steps
- Suitable for both metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to the induction motor
- Relatively heavy machine, requires a fixed location
- Manual belt change required for speed adjustment
Pros and cons
Pros
- Robust, vibration-damping construction
- Flexible speed control with 12 steps
- Suitable for both metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to the induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Manual belt change required for speed adjustment
Pros
- Robust, vibration-damping construction
- Flexible speed control with 12 steps
- Suitable for both metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to the induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Manual belt change required for speed adjustment
Specifications
- Model: DP58B Heavy Duty
- Manufacturer: Record
- Item number (SKU): RECDP58B-EP
- Voltage: 230V
- Motor power P1/P2: 0.6 kW / 0.37 kW
- Throat depth: 165 mm
- Drilling depth: 80 mm
- Chuck to table: 371 mm
- Chuck to base: 548 mm
- Chuck: 16 mm
- Speeds: 180, 250, 300, 400, 480, 580, 970, 1280, 1410, 1540, 2270, 2740 rpm
- Weight: 55 kg
- Dimensions: H1050 × W270 × D563 mm
The Rotwerk RB18 Vario is a bench drill designed for precision drilling in metal and other materials. It is equipped with a variable drive system (vario drive), which allows continuous spindle speed changes without the need to open or disassemble the machine.
The machine is powered by a 600 W motor and is designed to maintain torque across the entire speed range. This provides a stable and uniform drilling process regardless of speed. The drive system and construction are made in Germany, supporting the machine’s quality and durability.
The RB18 Vario has a drilling capacity of up to 18 mm in steel and an MK2 spindle taper. It is equipped with a drill chuck ranging from 1 to 16 mm and offers two speed ranges: 290–880 min⁻¹ and 880–2400 min⁻¹. The machine has a drilling depth of 50 mm and a throat depth of 115 mm.
With a column diameter of 60 mm, a column height of 600 mm and an overall height of 765 mm, the RB18 Vario is a stable and compact machine weighing approximately 31 kg. It is suitable for both workshops and hobby spaces where precision and flexibility are important.
- Variable drive system (Vario drive): Continuous spindle speed adjustment without disassembling the machine.
- Stable torque: Maintains power across the entire speed range.
- German manufacture: Drive system and construction made in Germany.
- Powerful motor: 600 W motor for demanding drilling tasks.
- Precision drilling: Drilling capacity up to 18 mm in steel.
Pros and cons
- Continuous speed control via the vario drive system
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby use
- Drive system made in Germany for high quality
- The relatively high weight of approximately 31 kg may reduce mobility
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros and cons
Pros
- Continuous speed control via the vario drive system
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby use
- Drive system made in Germany for high quality
Cons
- The relatively high weight of approximately 31 kg may reduce mobility
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros
- Continuous speed control via the vario drive system
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby use
- Drive system made in Germany for high quality
Cons
- The relatively high weight of approximately 31 kg may reduce mobility
- Limited drilling depth of 50 mm compared to larger pillar drills
Specifications
- Model: RB18 Vario
- Manufacturer: Rotwerk
- Supply voltage: 230 V / 50 Hz
- Power: 600 W
- Chuck: 1–16 mm
- Spindle taper: MK2
- Drilling capacity in steel: 18 mm
- Speed range I: 290–880 min⁻¹
- Speed range II: 880–2400 min⁻¹
- Torque range I: 5.3–4.0 Nm
- Torque range II: 1.8–1.3 Nm
- Throat depth: 115 mm
- Drilling depth: 50 mm
- Column diameter: 60 mm
- Column height: 600 mm
- Total height: 765 mm
- Weight: approx. 31 kg
- SKU: RB18VARIO
The Axminster Workshop AW285PD is a bench drill designed for smaller workshops and hobby use, where precision and stability are important. The machine is made of cast iron and machined steel, providing a solid base and reducing vibrations during operation.
It is powered by a 350 W induction motor, which provides smooth and quiet operation. The user can choose between five belt speeds from 600 to 2,500 revolutions per minute, allowing speed adjustment for different materials and drilling tasks.
The machine is equipped with a keyless chuck that can handle drill bits from 1 to 13 mm, as well as a depth control that ensures consistent holes. The table can be adjusted in height and tilted from 45° to 0° to 45°, offering flexibility for different tasks.
A front-mounted NVR switch and an adjustable safety guard contribute to safe operation. The belt cover also has a safety switch that prevents accidental start-up during speed changes. The combination of compact size and robust construction makes the AW285PD suitable for both beginners and experienced users who need a reliable drill for precision work.
- Solid construction: Cast iron and machined steel provide stability and reduce vibrations.
- Efficient motor: 350 W induction motor with smooth and quiet operation.
- Flexible speed control: Five belt speeds from 600 to 2,500 rpm.
- Keyless chuck: Allows quick change of drill bits between 1 and 13 mm.
- Adjustable table: The table can be raised, lowered and tilted for precise positioning.
- Safe operation: The NVR switch and safety guard enhance safety during use.
Pros and cons
- Robust, vibration-damping construction
- Smooth operation with induction motor
- Multiple speed settings for different materials
- Easy operation with keyless chuck
- Compact size suitable for smaller workshops
- Not suitable for mortising or very heavy drilling tasks
- The supplied British 3-pin plug may require an adapter for use in Denmark
Pros and cons
Pros
- Robust, vibration-damping construction
- Smooth operation with induction motor
- Multiple speed settings for different materials
- Easy operation with keyless chuck
- Compact size suitable for smaller workshops
Cons
- Not suitable for mortising or very heavy drilling tasks
- The supplied British 3-pin plug may require an adapter for use in Denmark
Pros
- Robust, vibration-damping construction
- Smooth operation with induction motor
- Multiple speed settings for different materials
- Easy operation with keyless chuck
- Compact size suitable for smaller workshops
Cons
- Not suitable for mortising or very heavy drilling tasks
- The supplied British 3-pin plug may require an adapter for use in Denmark
Specifications
- Model: AW285PD
- Item number (SKU): AX107690
- Voltage: 230 V
- Power: 350 W
- Speeds: 5 steps (600–2,500 rpm)
- Chuck capacity: 1–13 mm
- Chuck type: Keyless
- Chuck travel: 50 mm
- Column diameter: 46 mm
- Maximum chuck–spindle distance: 380 mm
- Maximum chuck–table distance: 285 mm
- Maximum drilling in mild steel: 13 mm
- Table size: 165 × 165 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 105 mm
- Dimensions (L × W × H): 500 × 280 × 735 mm
- Weight: 26 kg
- Plug type: British 3-pin
The PROMAC 371ELB bench drill is a stationary drill designed for precision work in metal and other hard materials. It is powered by a 400-volt motor with an output of 0.75 kW, providing stable operation and sufficient power for most workshop drilling tasks.
The machine has speed adjustment via a V-belt and offers 12 different speed levels in the range of 290–2300 revolutions per minute. This makes it possible to adjust the speed according to different materials and drill diameters.
The chuck is self-locking and can handle drills up to 16 mm in diameter. The worktable is equipped with adjustable cross grooves and can support up to 40 kg, providing flexibility when securing workpieces.
For increased safety, the machine is equipped with an emergency stop, protective screen and a system that prevents automatic restart after a power failure. An integrated LED lamp provides directional illumination of the drilling area, allowing work with high precision.
- Motor: 400 V, 0.75 kW with 12 speed levels via V-belt.
- Drilling capacity: Up to 16 mm in steel.
- Safety: Emergency stop, protective screen and anti-restart system.
- Worktable: Adjustable cross grooves and load capacity up to 40 kg.
- Lighting: Integrated LED lamp for better visibility during work.
Pros and cons
- Stable and powerful motor for precision drilling
- Possibility of speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with heavy weight for stability
- Requires 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt may take some time
Pros and cons
Pros
- Stable and powerful motor for precision drilling
- Possibility of speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with heavy weight for stability
Cons
- Requires 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt may take some time
Pros
- Stable and powerful motor for precision drilling
- Possibility of speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with heavy weight for stability
Cons
- Requires 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt may take some time
Specifications
- Motor voltage: 400 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number: 371ELB
The Holzmann SB4116HM 230V is a bench drill designed with a focus on stability and precision. The machine has a solid, polished base with T-slots, providing a secure foundation during work. The stainless steel column contributes to the rigidity and precision of the machine during drilling.
The motor is an aluminium motor with IP54 protection, offering a good balance between performance and durability. The worktable can tilt from -45° to +45° and rotate 360° around its axis, making it possible to drill at different angles and positions.
The machine comes with a self-tightening chuck (3–16 mm, B16), and the spindle is equipped with a protective cover for increased safety. The combination of adjustability, power and precision makes it suitable for both metal and wood processing in smaller workshops.
With a maximum drilling capacity of 16 mm, 12 speed levels from 180 to 2740 revolutions per minute and a maximum height of 1060 mm, the SB4116HM offers a flexible working platform for many types of drilling tasks.
- Powerful motor: 600 W (S1) / 900 W (S6) with IP54 protection.
- Adjustable worktable: Can tilt from -45° to +45° and rotate 360°.
- Solid construction: Stainless steel column and polished base with T-slots.
- Flexible drilling capacity: Up to 16 mm drilling diameter and 12 speed levels.
- Safety: Spindle protection and stable base for precise work.
Pros and cons
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for both metal and wood work
- Comes with self-tightening chuck
- The relatively high weight of 50 kg makes it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros and cons
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for both metal and wood work
- Comes with self-tightening chuck
Cons
- The relatively high weight of 50 kg makes it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for both metal and wood work
- Comes with self-tightening chuck
Cons
- The relatively high weight of 50 kg makes it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Specifications
- Model: SB4116HM 230V
- Motor power (S1/S6): 600 W / 900 W
- Voltage: 230 V
- Table dimensions: 250 × 250 mm
- Maximum height: 1060 mm
- Distance from chuck to column: 170 mm
- Maximum drilling stroke: 80 mm
- Base plate: 270 × 450 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 steps, 180–2740 min⁻¹
- Distance from spindle to base plate: 695 mm
- Distance between spindle and table: 495 mm
- Net weight: 50 kg
- Package dimensions (L×W×H): 895 × 490 × 290 mm
- Delivery contents: Self-tightening chuck 3–16 mm, B16
The Optimum OPTIdrill DQ 22 is a bench drill designed for precision work and stable operation. The machine is equipped with a separate emergency stop switch and drilling depth stop, which increases safety and allows drilling operations to be repeated with high accuracy.
The drilling table is precisely machined and can be tilted ±45° and rotated 360°, providing flexibility for various drilling tasks. The table has diagonally arranged T-slots and a cooling channel around it, making it suitable for metalworking.
The machine has a die-cast aluminium lever arm with a soft grip, and the spindle is mounted with precision ball bearings to ensure concentricity of less than 0.03 mm. The quick-action chuck and GATES quality belt contribute to smooth and reliable operation.
With a speed range from 300 to 2300 revolutions per minute distributed over 12 steps, the machine can be adapted to different materials and drilling types. It is powered by a 0.55 kW motor at 230 V, making it suitable for standard workshop installations.
- Precision spindle: Guaranteed concentricity less than 0.03 mm.
- Flexible drilling table: Can be tilted ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium lever arm and heavy base plate with T-slots.
- Variable speed: 12-step gearbox with range from 300 to 2300 min⁻¹.
- Safe operation: Separate emergency stop and 24 V DC safety voltage.
Pros and cons
- High precision and stability during drilling
- Adjustable drilling table with great freedom of movement
- Robust aluminium and steel construction
- Wide speed range with 12 steps
- Suitable for precision work in metal
- The relatively high weight of approximately 42 kg can make moving difficult
- Requires a fixed workstation and proper setup for optimal stability
Pros and cons
Pros
- High precision and stability during drilling
- Adjustable drilling table with great freedom of movement
- Robust aluminium and steel construction
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- The relatively high weight of approximately 42 kg can make moving difficult
- Requires a fixed workstation and proper setup for optimal stability
Pros
- High precision and stability during drilling
- Adjustable drilling table with great freedom of movement
- Robust aluminium and steel construction
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- The relatively high weight of approximately 42 kg can make moving difficult
- Requires a fixed workstation and proper setup for optimal stability
Specifications
- Model: OPTIdrill DQ 22
- Supply voltage: 230 V
- Power: 0.55 kW
- Mains frequency: 50 Hz
- Speed range: 300–2300 min⁻¹ (12 steps)
- Column diameter: 70 mm
- Drilling capacity in steel (S235JR): 20 mm
- Continuous drilling capacity in steel (S235JR): 16 mm
- Drilling table: 270 × 270 mm, 14 mm T-slot, 2 slots, 360° rotation, ±45° angle
- Maximum distance spindle – drilling table: 460 mm
- Maximum distance spindle – machine base: 639 mm
- Spindle taper: MK 2
- Spindle travel: 85 mm
- Throat depth: 169 mm
- Dimensions (L×W×H): approx. 700 × 351 × 1006 mm
- Weight: approx. 41.7 kg
- Drilling table load capacity: 15 kg
The Proxxon TBM 220 is a small but powerful bench drill designed for precision work. It can drill holes down to 0.5 mm, making it suitable for tasks where accuracy and control are more important than brute power.
The machine is equipped with a milled flat worktable made of die-cast aluminium, measuring 220 x 120 mm, providing a stable and flat surface. The table has both a parallel stop and a scale, making precise work with repeated drilling easier.
The hard-chromed steel column, measuring 20 x 280 mm, ensures stability, while the die-cast aluminium arm with precise guides contributes to a rigid, low-vibration construction.
The TBM 220 is powered by a quiet and durable VDE-tested motor with a three-step belt drive, offering three different speeds: 1,800, 4,700, and 8,500 revolutions per minute. By changing the belt, the user can choose between high speed for small drills and lower speed with increased torque for larger drills.
The machine has a quill stroke of 30 mm and a throat depth of 140 mm (distance from the centre of the column to the centre of the drill). It is supplied with six MICROMOT collets in sizes 1.0 – 3.2 mm, as well as a thread for mounting a keyed chuck.
- Precision drilling: Can drill holes down to 0.5 mm in diameter.
- Three-step belt drive: Offers three speeds – 1,800, 4,700, and 8,500 rpm.
- Stable construction: Milled flat worktable and hard-chromed steel column ensure accuracy.
- Quality motor: VDE-tested motor with low noise level and long service life.
- Included collets: Six MICROMOT collets from 1.0 to 3.2 mm.
Pros and cons
- High precision and stability for small drilling tasks
- Three speed levels adapted to different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros and cons
Pros
- High precision and stability for small drilling tasks
- Three speed levels adapted to different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros
- High precision and stability for small drilling tasks
- Three speed levels adapted to different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Specifications
- Model: TBM 220
- Item number (SKU): ROL-28128
- Voltage: 220–240 V
- Power: 85 W
- Frequency: 50–60 Hz
- Speed: 1,800 / 4,700 / 8,500 rpm
- Throat depth: 140 mm
- Quill stroke: 30 mm
- Worktable: 220 x 120 mm, milled flat die-cast aluminium
- Column: 20 x 280 mm, hard-chromed steel
- Collets: 6 pcs. MICROMOT (1.0 – 3.2 mm)
- Thread for chuck: 3/8"
- EAN / Barcode: ROL-28128
The Axminster Professional AP20BD is a bench drill designed to deliver precise results and stable operation in workshop environments. The machine is equipped with a precision spindle that runs in NSK ball bearings, reducing vibrations and ensuring smooth rotation during drilling.
The drive system uses Multi-V belts, which provide good grip and contribute to quiet and stable operation. The spindle unit is solidly integrated into the machine head, increasing the overall rigidity and precision of the machine.
Safety is a priority, with an electrically interlocked chuck guard that prevents accidental start-up, as well as a safety switch that cuts power when the belt cover is open. An integrated LED work light provides good illumination of the work area.
The machine has an ergonomic cast iron handle with a rubber grip for comfortable operation. The keyless chuck allows quick drill bit changes, and the table can be adjusted via rack and pinion. An improved depth stop allows drilling with high precision.
Thanks to its compact dimensions and solid construction, the AP20BD is suitable for both professional workshops and demanding hobby users who want a stable and precise bench drill.
- Precision spindle with NSK bearings: Provides stable and vibration-free drilling.
- Multi-V belt drive: Ensures smooth power transmission and low noise level.
- Safety switches: Prevent operation with the cover open or without protection.
- LED work light: Improves visibility during work.
- Ergonomic design: Cast iron handle with rubber grip for comfortable operation.
- Keyless chuck: Quick and easy drill bit change.
Pros and cons
- Robust construction with high precision
- Reduced vibrations and stable operation
- Safety switches and protection against accidental start-up
- Easy adjustment of table and drilling depth
- Built-in LED light for better illumination of the work area
- The relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient room
- Speed adjustment is done manually via pulleys
Pros and cons
Pros
- Robust construction with high precision
- Reduced vibrations and stable operation
- Safety switches and protection against accidental start-up
- Easy adjustment of table and drilling depth
- Built-in LED light for better illumination of the work area
Cons
- The relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient room
- Speed adjustment is done manually via pulleys
Pros
- Robust construction with high precision
- Reduced vibrations and stable operation
- Safety switches and protection against accidental start-up
- Easy adjustment of table and drilling depth
- Built-in LED light for better illumination of the work area
Cons
- The relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient room
- Speed adjustment is done manually via pulleys
Specifications
- Model: AP20BD
- Voltage: 230 V
- Power: 750 W
- Speed range: 120 – 2,580 rpm
- Chuck capacity: 1 – 16 mm (keyless)
- Spindle travel: 80 mm
- Morse taper: 2 MT
- Spindle taper: 2 MT
- Column diameter: 80 mm
- Maximum drilling in mild steel: 20 mm
- Maximum distance chuck - base: 500 mm
- Maximum distance chuck - table: 325 mm
- Table size: 290 × 290 mm
- Table tilt: 45° – 0° – 45°
- Base size: 450 × 270 mm
- Throat depth: 178 mm
- Overall dimensions (L × W × H): 670 × 360 × 1,020 mm
- Net weight: 82 kg
- Plug type: EU 2-pin plug
- Classification: Craftsman/Professional
The PROMAC 212 bench drill is a stationary machine designed for precision work in metal and other hard materials. It is equipped with a single-speed motor and speed adjustment via a V-belt, providing stable operation and the ability to adapt the rotation speed to different drilling tasks.
The machine is supplied with a 16 mm self-tightening chuck, safety screen and emergency stop button, which enhance safety during use. The table is adjustable and has cross grooves, facilitating secure clamping of workpieces during drilling.
An integrated safety system prevents automatic restart after a power failure, contributing to a safer working process. Its compact size and weight of 45 kg make it suitable for both workshops and smaller production environments where a stable and precise drill is required.
- 16 mm drilling capacity: Suitable for drilling in steel and other metals.
- Speed adjustment via V-belt: Offers flexibility depending on the material and type of drilling.
- Self-tightening chuck: Quick and secure clamping of drill bits without using a key.
- Adjustable table with cross grooves: Allows precise positioning of workpieces.
- Safety system against automatic start-up: Increases safety during power interruptions.
Pros and cons
- Stable construction, suitable for workshop use
- Easy speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for a flexible working position
- Single motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust rotation speed
Pros and cons
Pros
- Stable construction, suitable for workshop use
- Easy speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for a flexible working position
Cons
- Single motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust rotation speed
Pros
- Stable construction, suitable for workshop use
- Easy speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for a flexible working position
Cons
- Single motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust rotation speed
Specifications
- Motor voltage: 230 V
- Motor power: 0.37 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 5 steps
- Speed range: 490–2510 min⁻¹
- Maximum table load: 30 kg
- T-slot: 12 mm
- Weight: 45 kg
- Dimensions (A–J): A: 970 mm, B: 560 mm, C: 640 mm, D: 168 mm, E: 73 mm, F: 40 mm, G: 445 mm, H: 320 mm, I: 265 mm, J: 265 mm
- Item number (SKU): 212
Product descriptions
The JET 210 Z Bench Drill is a compact and stable machine designed for precision drilling in various materials. It comes with a keyed chuck (0.5–13 mm) and a 75 mm vice, ready for use straight out of the box.
The machine is equipped with a safety device combined with the chuck drive and an emergency stop button located at the front for increased safety during operation. Speed changes are made via belt transmission, allowing adjustment of drilling speed according to the material.
The drill table has two parallel 12 mm slots, and the spindle can travel 53 mm in stroke length. With a B16 spindle taper and a maximum drilling diameter of 10 mm, the machine is suitable for precision work on smaller parts.
The motor operates at 230V and delivers 0.19 kW. The machine has five speeds, ranging from 600 to 2600 revolutions per minute, providing flexibility for different drilling tasks. Its compact size and weight of 32 kg make it easy to place on a workbench.
The JET 210 Z is built with a focus on reliability and ease of use, making it suitable for both hobby workshops and light professional use.
- Five speeds: Adjustable drilling speed from 600 to 2600 rpm via belt transmission.
- Safe operation: Equipped with emergency stop and chuck safety device.
- Compact design: Fits well on workbenches in smaller workshops.
- Stable construction: The 32 kg weight provides good stability during drilling.
- Ready to use: Includes keyed chuck (0.5–13 mm) and 75 mm vice.
Pros and cons
- Stable and compact construction
- Multiple speed settings via belt transmission
- Integrated emergency stop for increased safety
- Comes with relevant accessories
- Drilling capacity limited to max. 10 mm
- Manual speed adjustment requires belt change
Pros and cons
Pros
- Stable and compact construction
- Multiple speed settings via belt transmission
- Integrated emergency stop for increased safety
- Comes with relevant accessories
Cons
- Drilling capacity limited to max. 10 mm
- Manual speed adjustment requires belt change
Pros
- Stable and compact construction
- Multiple speed settings via belt transmission
- Integrated emergency stop for increased safety
- Comes with relevant accessories
Cons
- Drilling capacity limited to max. 10 mm
- Manual speed adjustment requires belt change
Specifications
- Model: 210 Z
- Manufacturer: JET
- Motor voltage: 230 V
- Motor power: 0.19 kW
- Spindle taper: B16
- Maximum drilling diameter: Ø10 mm
- Working depth: 105 mm
- Spindle travel: 53 mm
- Speeds: 5 steps (600–2600 rpm)
- Drill table: 2 parallel 12 mm slots
- Slots (number/size): T12
- Weight: 32 kg
- Dimensions (L×W×H): 600 × 420 × 240 mm
- Included accessories: Keyed chuck 0.5–13 mm, 75 mm vice
The Axminster Workshop AW315PD is a bench drill made of cast iron and machined steel, providing high stability and reducing vibrations during use. It is equipped with a quiet 550 W induction motor that drives the spindle through a belt system with 12 different speeds, ranging from 210 to 2,580 revolutions per minute.
The machine has a keyless chuck with a capacity from 1 to 16 mm, making it easy to change drill bits without tools. The drilling depth can be precisely adjusted, and the feed handle is fitted with soft grips for better control.
The table height is adjusted via a rack and pinion system, and the entire table can be rotated so that the machine base can be used as a support for larger workpieces. An adjustable safety guard and a front-mounted NVR switch contribute to safe operation.
The AW315PD is suitable for precision drilling in wood, plastic and metals and is a practical choice for users who want a stable and reliable machine for workshop use.
- Cast iron construction: Provides stability and reduces vibrations during drilling.
- 550 W induction motor: Ensures quiet and reliable operation.
- 12 speeds: From 210 to 2,580 rpm for different materials and drilling tasks.
- Keyless chuck: Quick and easy drill bit changes from 1 to 16 mm.
- Adjustable table: Height and angle can be adjusted via the rack and pinion system.
Pros and cons
- Robust cast iron construction that dampens vibrations
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick drill bit changes
- Suitable for precision work in multiple materials
- Not compatible with mortising attachments
- The relatively heavy 37 kg construction may require a fixed position
Pros and cons
Pros
- Robust cast iron construction that dampens vibrations
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick drill bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with mortising attachments
- The relatively heavy 37 kg construction may require a fixed position
Pros
- Robust cast iron construction that dampens vibrations
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick drill bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with mortising attachments
- The relatively heavy 37 kg construction may require a fixed position
Specifications
- Model: AW315PD
- Item number (SKU): AX107691
- Voltage: 230 V
- Power: 550 W
- Speeds: 12 steps (210–2,580 rpm)
- Chuck capacity: 1–16 mm
- Chuck type: Keyless
- Chuck travel: 60 mm
- Column diameter: 60 mm
- Maximum chuck–spindle distance: 430 mm
- Maximum chuck–table distance: 315 mm
- Maximum drilling in mild steel: 16 mm
- Table size: 198 × 198 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 127 mm
- Dimensions (L × W × H): 520 × 260 × 840 mm
- Weight: 37 kg
- Plug type: British 3-pin plug
- User level: Home workshop
The PROMAC Bench Drill 370ELB is a stationary machine designed for precision drilling in metal and other hard materials. The machine is powered by a 230 V motor with an output of 0.75 kW and has a single speed, which is adjusted via a V-belt.
It is equipped with a 16 mm self-tightening chuck, protective screen and emergency stop button for increased safety during use. The worktable has adjustable cross grooves that provide flexibility when securing workpieces, and a safety system prevents automatic restart after a power failure.
An integrated LED work light provides directional illumination of the drilling area, improving accuracy when working on detailed pieces. The machine’s construction and weight of 74 kg contribute to stable operation with minimal vibration.
With a speed range from 290 to 2300 revolutions per minute and a drilling depth of up to 80 mm, the 370ELB is suitable for a wide range of workshop drilling tasks.
- Single-speed motor: Simple and reliable design with V-belt adjustment.
- Self-tightening chuck: Allows quick drill bit changes without using a key.
- Safety features: Protective screen, emergency stop and system against automatic restart.
- LED work light: Provides precise illumination of the drilling area.
- Stable construction: The machine’s weight of 74 kg reduces vibrations during operation.
Pros and cons
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED light for better illumination of the work area
- Safety system against automatic start-up
- Suitable for precision drilling in metal
- Single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires fixed placement on the workbench
Pros and cons
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED light for better illumination of the work area
- Safety system against automatic start-up
- Suitable for precision drilling in metal
Cons
- Single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires fixed placement on the workbench
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED light for better illumination of the work area
- Safety system against automatic start-up
- Suitable for precision drilling in metal
Cons
- Single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires fixed placement on the workbench
Specifications
- Motor voltage: 230 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12 steps
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number / SKU: 370ELB
The Holzmann ZS40HS 400V is a stationary bench drill designed for precision work in metal and wood. It is equipped with an extra-large cast iron worktable that can be adjusted in height and rotated 360 degrees around the central axis. The table has 14 mm T-slots, allowing secure clamping of workpieces and accessories during operation.
The machine’s gear head can be adjusted in height and tilted, providing flexibility when drilling at different angles. The gears are oil-bathed to ensure smooth and quiet operation as well as a long service life. The powerful motor provides continuous drilling power, making the machine suitable for demanding tasks.
For increased safety, the spindle guard is height-adjustable and equipped with a microswitch. The machine comes with a drill chuck (16 mm), reducers (MT4/3 and MT3/2), wedge and extraction rod, so it can be used immediately.
With a maximum height of over two metres and a weight of 320 kg, the ZS40HS 400V is a stable and solid machine built for precision and durability in workshop environments.
- XL worktable: Large cast iron table (550 × 480 mm) with 360° rotation and T-slots.
- Adjustable gear head: Can be tilted and height-adjusted for flexible drilling.
- Oil bath gearbox: Ensures smooth operation and reduced wear.
- Powerful motor: Provides continuous drilling power for demanding tasks.
- Safety feature: Spindle guard with microswitch for increased safety.
Pros and cons
- Solid cast iron construction
- Large working surface with flexible adjustment
- Oil bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
- The heavy weight of 320 kg requires a fixed installation
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros and cons
Pros
- Solid cast iron construction
- Large working surface with flexible adjustment
- Oil bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- The heavy weight of 320 kg requires a fixed installation
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros
- Solid cast iron construction
- Large working surface with flexible adjustment
- Oil bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- The heavy weight of 320 kg requires a fixed installation
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Specifications
- Model: ZS40HS 400V
- Manufacturer: Holzmann
- Motor power (S6/S1): 1500/1100 W
- Voltage: 400 V
- Cable length: 2.5 m
- Table size: 550 × 480 mm
- Maximum height: 2120 mm
- Spindle travel: 120 mm
- Spindle–base distance: 1250 mm
- Maximum spindle–table distance: 790 mm
- Weight: 320 kg
- Included accessories: 16 mm drill chuck, MT4/3 and MT3/2 reducers, wedge, extraction rod
The Scheppach DP16VLS is a stationary bench drill designed for precision drilling in various materials such as metal and wood. The integrated positioning laser helps to accurately mark the drilling point, making the work more efficient and precise.
The machine is powered by a 500 W motor that operates at 230 volts and offers five different speeds, from 600 to 2600 revolutions per minute. This allows the user to adjust the speed according to the material and drilling task.
The drill chuck ranges from 3 to 16 mm, and the maximum drilling size is 16 mm. The worktable measures 160 x 168 mm, and the column diameter is 46 mm, providing stability during drilling. The spindle travel is 46 mm, and the machine has an overall size of 460 x 255 x 630 mm.
Weighing 17 kg, the DP16VLS is light enough to be moved when needed, yet robust enough to remain stable during use. A vice is included as standard, increasing flexibility when securing workpieces.
- Positioning laser: Provides accurate marking of the drilling point.
- Flexible speed control: Five speeds from 600 to 2600 rpm.
- Powerful motor: 500 W motor for various drilling tasks.
- Stable construction: 46 mm column diameter and solid base for safe operation.
- Included vice: Facilitates securing workpieces during drilling.
Pros and cons
- Integrated laser for precise drilling
- Multiple speed settings for different materials
- Compact and stable construction
- Included vice increases usability
- Limited spindle travel of 46 mm can be challenging for deeper drilling
- Not intended for heavy industrial use
Pros and cons
Pros
- Integrated laser for precise drilling
- Multiple speed settings for different materials
- Compact and stable construction
- Included vice increases usability
Cons
- Limited spindle travel of 46 mm can be challenging for deeper drilling
- Not intended for heavy industrial use
Pros
- Integrated laser for precise drilling
- Multiple speed settings for different materials
- Compact and stable construction
- Included vice increases usability
Cons
- Limited spindle travel of 46 mm can be challenging for deeper drilling
- Not intended for heavy industrial use
Specifications
- Motor power: 500 W – 230 V
- Revolutions/min: 1450
- Speeds: 600 / 900 / 1300 / 1800 / 2600 rpm
- Chuck: 3–16 mm
- Maximum drilling size: 16 mm
- Worktable: 160 × 168 mm
- Column diameter: 46 mm
- Spindle travel: 46 mm
- Dimensions (L × W × H): 460 × 255 × 630 mm
- Weight: 17 kg
- Included accessories: Vice
- Item number (SKU): 5906810901
The Optimum OPTIdrill DQ 14 is a bench drill designed for precision drilling in metal and other materials. The machine is made of die-cast aluminium and equipped with soft-grip handles, providing stable and comfortable operation.
The drilling table can tilt ±45° and rotate 360°, offering flexibility for various drilling tasks. A clear depth scale and a separate emergency stop button contribute to safe and controlled operation.
The spindle is equipped with precision bearings and offers a concentricity accuracy of less than 0.03 mm, making the machine suitable for tasks where precision is essential. The quick-action chuck and GATES quality belt ensure efficient power transmission.
With a motor power of 0.35 kW and a speed range from 700 to 2500 revolutions per minute in five steps, the machine can be adapted to different materials and drilling types. The large base plate with T-slots provides stability during operation.
- Precision drilling: Concentricity accuracy below 0.03 mm for high precision.
- Flexible drilling table: Can be tilted ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium with soft-grip handles for stability and comfort.
- Efficient power transmission: Equipped with GATES quality belt and precision bearings.
- Safe operation: Separate emergency stop and 24 V DC safety voltage.
Pros and cons
- High precision and stable operation
- Adjustable and rotatable drilling table
- Robust aluminium construction
- Compact size suitable for workbenches
- Safety features such as emergency stop and low voltage
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros and cons
Pros
- High precision and stable operation
- Adjustable and rotatable drilling table
- Robust aluminium construction
- Compact size suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros
- High precision and stable operation
- Adjustable and rotatable drilling table
- Robust aluminium construction
- Compact size suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Specifications
- Manufacturer: Optimum
- Model: OPTIdrill DQ 14
- SKU: SM-3191040
- Column diameter: 46 mm
- Length: approx. 472 mm
- Width/depth: approx. 283 mm
- Height: approx. 634 mm
- Weight: approx. 18.5 kg
- Drilling capacity in steel (S235JR): 13 mm
- Continuous drilling capacity in steel (S235JR): 12 mm
- Drilling table size: 170 × 170 mm
- T-slot size: 14 mm (2 pcs., diagonal type)
- Drilling table rotation: 360°
- Drilling table angle: ±45°
- Maximum distance spindle – drilling table: 250 mm
- Maximum distance spindle – machine base: 340 mm
- Drive motor power: 0.35 kW
- Supply voltage: 230 V
- Mains frequency: 50 Hz
- Speed range: 700–2500 min⁻¹ (5 steps)
- Spindle travel: 52 mm
- Spindle chuck: B16
- Throat depth: 104 mm
The Proxxon TBH is a bench drill developed for precision work, where stability and accuracy are essential. The machine is powered by a strong and durable DC motor that ensures smooth operation and constant torque under load.
The height is easily adjusted via a rack-and-pinion mechanism and crank handle, providing precise control over the drilling position. The spindle drive is equipped with three pulleys, allowing three speed levels – 1080, 2400 and 4500 revolutions per minute – so the user can adapt the speed to the material.
The machine has a drilling depth scale with adjustable stop, and the drill spindle is mounted in precision bearings to ensure stable operation. The spindle head has a 1/2" thread and fits an industrial-quality RÖHM chuck. In addition, the spindle can be equipped with collars (no. 28200) for additional precision work.
With a column of 45 x 500 mm, a worktable of 200 x 200 mm and a weight of approximately 10 kg, the TBH is both stable and compact, making it suitable for smaller workshops and precision tasks in metal and plastic.
- DC motor: Durable motor with stable operation and low vibration.
- Stepwise speed control: Three speed levels (1080, 2400 and 4500 rpm) for different materials.
- Precise height adjustment: Rack and crank handle for easy and accurate adjustment.
- Stable construction: Column and table with robust design for precision drilling.
- Compatibility: Fits RÖHM chuck and collars no. 28200.
Pros and cons
- Precise and stable operation thanks to spindle bearings
- Long service life due to DC motor
- Easy height adjustment with crank handle
- Possibility to use collars for precision drilling
- Compact and solid construction
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change for speed adjustment
Pros and cons
Pros
- Precise and stable operation thanks to spindle bearings
- Long service life due to DC motor
- Easy height adjustment with crank handle
- Possibility to use collars for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change for speed adjustment
Pros
- Precise and stable operation thanks to spindle bearings
- Long service life due to DC motor
- Easy height adjustment with crank handle
- Possibility to use collars for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change for speed adjustment
Specifications
- Voltage: 220–240 V
- Speeds: 1080 / 2400 / 4500 rpm
- Spindle travel: 63 mm
- Height adjustment: 70 mm via crank handle
- Throat depth: 120 mm
- Table working surface: 200 × 200 mm
- Column: 45 × 500 mm
- Maximum drilling capacity in steel: 10 mm
- Clamping range: up to 10 mm
- Weight: approx. 10 kg
- Compatible chuck: RÖHM chuck (1/2" thread)
- Collar option: no. 28200
- SKU: ROL-28124
The Record DP58B Heavy Duty is a stationary bench drill made of steel and cast iron to ensure stability and long service life. It is equipped with a powerful induction motor that provides smooth operation and can handle both hardwood and metal pieces.
The machine has a cast iron table with grooves that allow secure clamping of a vice. The table can tilt up to 45 degrees, offering flexibility for angled drilling. A rack and pinion system makes height adjustment easy.
With 12 different speeds, the user can adjust the rotation speed according to the material, making the machine suitable for many types of drilling work. The spindle housing is designed to minimise vibrations and ensure precision during operation.
The machine has a maximum chuck capacity of 16 mm, a weight of 55 kg and a total height of 1050 mm, making it suitable for both professional users and hobbyists who want a stable and precise bench drill.
- 12 speeds: Allows precise adjustment for different materials.
- Cast iron table: Can tilt up to 45° and has grooves for securing a vice.
- Induction motor: Provides stable power for drilling in wood and metal.
- Solid construction: Steel and cast iron reduce vibrations and increase precision.
- Ergonomic design: Handles and height adjustment are designed for easy operation.
Pros and cons
- Robust, vibration-damping construction
- Flexible speed control with 12 steps
- Suitable for both metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to the induction motor
- Relatively heavy machine, requires a fixed location
- Manual belt change required for speed adjustment
Pros and cons
Pros
- Robust, vibration-damping construction
- Flexible speed control with 12 steps
- Suitable for both metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to the induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Manual belt change required for speed adjustment
Pros
- Robust, vibration-damping construction
- Flexible speed control with 12 steps
- Suitable for both metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to the induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Manual belt change required for speed adjustment
Specifications
- Model: DP58B Heavy Duty
- Manufacturer: Record
- Item number (SKU): RECDP58B-EP
- Voltage: 230V
- Motor power P1/P2: 0.6 kW / 0.37 kW
- Throat depth: 165 mm
- Drilling depth: 80 mm
- Chuck to table: 371 mm
- Chuck to base: 548 mm
- Chuck: 16 mm
- Speeds: 180, 250, 300, 400, 480, 580, 970, 1280, 1410, 1540, 2270, 2740 rpm
- Weight: 55 kg
- Dimensions: H1050 × W270 × D563 mm
The Rotwerk RB18 Vario is a bench drill designed for precision drilling in metal and other materials. It is equipped with a variable drive system (vario drive), which allows continuous spindle speed changes without the need to open or disassemble the machine.
The machine is powered by a 600 W motor and is designed to maintain torque across the entire speed range. This provides a stable and uniform drilling process regardless of speed. The drive system and construction are made in Germany, supporting the machine’s quality and durability.
The RB18 Vario has a drilling capacity of up to 18 mm in steel and an MK2 spindle taper. It is equipped with a drill chuck ranging from 1 to 16 mm and offers two speed ranges: 290–880 min⁻¹ and 880–2400 min⁻¹. The machine has a drilling depth of 50 mm and a throat depth of 115 mm.
With a column diameter of 60 mm, a column height of 600 mm and an overall height of 765 mm, the RB18 Vario is a stable and compact machine weighing approximately 31 kg. It is suitable for both workshops and hobby spaces where precision and flexibility are important.
- Variable drive system (Vario drive): Continuous spindle speed adjustment without disassembling the machine.
- Stable torque: Maintains power across the entire speed range.
- German manufacture: Drive system and construction made in Germany.
- Powerful motor: 600 W motor for demanding drilling tasks.
- Precision drilling: Drilling capacity up to 18 mm in steel.
Pros and cons
- Continuous speed control via the vario drive system
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby use
- Drive system made in Germany for high quality
- The relatively high weight of approximately 31 kg may reduce mobility
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros and cons
Pros
- Continuous speed control via the vario drive system
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby use
- Drive system made in Germany for high quality
Cons
- The relatively high weight of approximately 31 kg may reduce mobility
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros
- Continuous speed control via the vario drive system
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby use
- Drive system made in Germany for high quality
Cons
- The relatively high weight of approximately 31 kg may reduce mobility
- Limited drilling depth of 50 mm compared to larger pillar drills
Specifications
- Model: RB18 Vario
- Manufacturer: Rotwerk
- Supply voltage: 230 V / 50 Hz
- Power: 600 W
- Chuck: 1–16 mm
- Spindle taper: MK2
- Drilling capacity in steel: 18 mm
- Speed range I: 290–880 min⁻¹
- Speed range II: 880–2400 min⁻¹
- Torque range I: 5.3–4.0 Nm
- Torque range II: 1.8–1.3 Nm
- Throat depth: 115 mm
- Drilling depth: 50 mm
- Column diameter: 60 mm
- Column height: 600 mm
- Total height: 765 mm
- Weight: approx. 31 kg
- SKU: RB18VARIO
The Axminster Workshop AW285PD is a bench drill designed for smaller workshops and hobby use, where precision and stability are important. The machine is made of cast iron and machined steel, providing a solid base and reducing vibrations during operation.
It is powered by a 350 W induction motor, which provides smooth and quiet operation. The user can choose between five belt speeds from 600 to 2,500 revolutions per minute, allowing speed adjustment for different materials and drilling tasks.
The machine is equipped with a keyless chuck that can handle drill bits from 1 to 13 mm, as well as a depth control that ensures consistent holes. The table can be adjusted in height and tilted from 45° to 0° to 45°, offering flexibility for different tasks.
A front-mounted NVR switch and an adjustable safety guard contribute to safe operation. The belt cover also has a safety switch that prevents accidental start-up during speed changes. The combination of compact size and robust construction makes the AW285PD suitable for both beginners and experienced users who need a reliable drill for precision work.
- Solid construction: Cast iron and machined steel provide stability and reduce vibrations.
- Efficient motor: 350 W induction motor with smooth and quiet operation.
- Flexible speed control: Five belt speeds from 600 to 2,500 rpm.
- Keyless chuck: Allows quick change of drill bits between 1 and 13 mm.
- Adjustable table: The table can be raised, lowered and tilted for precise positioning.
- Safe operation: The NVR switch and safety guard enhance safety during use.
Pros and cons
- Robust, vibration-damping construction
- Smooth operation with induction motor
- Multiple speed settings for different materials
- Easy operation with keyless chuck
- Compact size suitable for smaller workshops
- Not suitable for mortising or very heavy drilling tasks
- The supplied British 3-pin plug may require an adapter for use in Denmark
Pros and cons
Pros
- Robust, vibration-damping construction
- Smooth operation with induction motor
- Multiple speed settings for different materials
- Easy operation with keyless chuck
- Compact size suitable for smaller workshops
Cons
- Not suitable for mortising or very heavy drilling tasks
- The supplied British 3-pin plug may require an adapter for use in Denmark
Pros
- Robust, vibration-damping construction
- Smooth operation with induction motor
- Multiple speed settings for different materials
- Easy operation with keyless chuck
- Compact size suitable for smaller workshops
Cons
- Not suitable for mortising or very heavy drilling tasks
- The supplied British 3-pin plug may require an adapter for use in Denmark
Specifications
- Model: AW285PD
- Item number (SKU): AX107690
- Voltage: 230 V
- Power: 350 W
- Speeds: 5 steps (600–2,500 rpm)
- Chuck capacity: 1–13 mm
- Chuck type: Keyless
- Chuck travel: 50 mm
- Column diameter: 46 mm
- Maximum chuck–spindle distance: 380 mm
- Maximum chuck–table distance: 285 mm
- Maximum drilling in mild steel: 13 mm
- Table size: 165 × 165 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 105 mm
- Dimensions (L × W × H): 500 × 280 × 735 mm
- Weight: 26 kg
- Plug type: British 3-pin
The PROMAC 371ELB bench drill is a stationary drill designed for precision work in metal and other hard materials. It is powered by a 400-volt motor with an output of 0.75 kW, providing stable operation and sufficient power for most workshop drilling tasks.
The machine has speed adjustment via a V-belt and offers 12 different speed levels in the range of 290–2300 revolutions per minute. This makes it possible to adjust the speed according to different materials and drill diameters.
The chuck is self-locking and can handle drills up to 16 mm in diameter. The worktable is equipped with adjustable cross grooves and can support up to 40 kg, providing flexibility when securing workpieces.
For increased safety, the machine is equipped with an emergency stop, protective screen and a system that prevents automatic restart after a power failure. An integrated LED lamp provides directional illumination of the drilling area, allowing work with high precision.
- Motor: 400 V, 0.75 kW with 12 speed levels via V-belt.
- Drilling capacity: Up to 16 mm in steel.
- Safety: Emergency stop, protective screen and anti-restart system.
- Worktable: Adjustable cross grooves and load capacity up to 40 kg.
- Lighting: Integrated LED lamp for better visibility during work.
Pros and cons
- Stable and powerful motor for precision drilling
- Possibility of speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with heavy weight for stability
- Requires 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt may take some time
Pros and cons
Pros
- Stable and powerful motor for precision drilling
- Possibility of speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with heavy weight for stability
Cons
- Requires 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt may take some time
Pros
- Stable and powerful motor for precision drilling
- Possibility of speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with heavy weight for stability
Cons
- Requires 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt may take some time
Specifications
- Motor voltage: 400 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number: 371ELB
The Holzmann SB4116HM 230V is a bench drill designed with a focus on stability and precision. The machine has a solid, polished base with T-slots, providing a secure foundation during work. The stainless steel column contributes to the rigidity and precision of the machine during drilling.
The motor is an aluminium motor with IP54 protection, offering a good balance between performance and durability. The worktable can tilt from -45° to +45° and rotate 360° around its axis, making it possible to drill at different angles and positions.
The machine comes with a self-tightening chuck (3–16 mm, B16), and the spindle is equipped with a protective cover for increased safety. The combination of adjustability, power and precision makes it suitable for both metal and wood processing in smaller workshops.
With a maximum drilling capacity of 16 mm, 12 speed levels from 180 to 2740 revolutions per minute and a maximum height of 1060 mm, the SB4116HM offers a flexible working platform for many types of drilling tasks.
- Powerful motor: 600 W (S1) / 900 W (S6) with IP54 protection.
- Adjustable worktable: Can tilt from -45° to +45° and rotate 360°.
- Solid construction: Stainless steel column and polished base with T-slots.
- Flexible drilling capacity: Up to 16 mm drilling diameter and 12 speed levels.
- Safety: Spindle protection and stable base for precise work.
Pros and cons
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for both metal and wood work
- Comes with self-tightening chuck
- The relatively high weight of 50 kg makes it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros and cons
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for both metal and wood work
- Comes with self-tightening chuck
Cons
- The relatively high weight of 50 kg makes it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for both metal and wood work
- Comes with self-tightening chuck
Cons
- The relatively high weight of 50 kg makes it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Specifications
- Model: SB4116HM 230V
- Motor power (S1/S6): 600 W / 900 W
- Voltage: 230 V
- Table dimensions: 250 × 250 mm
- Maximum height: 1060 mm
- Distance from chuck to column: 170 mm
- Maximum drilling stroke: 80 mm
- Base plate: 270 × 450 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 steps, 180–2740 min⁻¹
- Distance from spindle to base plate: 695 mm
- Distance between spindle and table: 495 mm
- Net weight: 50 kg
- Package dimensions (L×W×H): 895 × 490 × 290 mm
- Delivery contents: Self-tightening chuck 3–16 mm, B16
The Optimum OPTIdrill DQ 22 is a bench drill designed for precision work and stable operation. The machine is equipped with a separate emergency stop switch and drilling depth stop, which increases safety and allows drilling operations to be repeated with high accuracy.
The drilling table is precisely machined and can be tilted ±45° and rotated 360°, providing flexibility for various drilling tasks. The table has diagonally arranged T-slots and a cooling channel around it, making it suitable for metalworking.
The machine has a die-cast aluminium lever arm with a soft grip, and the spindle is mounted with precision ball bearings to ensure concentricity of less than 0.03 mm. The quick-action chuck and GATES quality belt contribute to smooth and reliable operation.
With a speed range from 300 to 2300 revolutions per minute distributed over 12 steps, the machine can be adapted to different materials and drilling types. It is powered by a 0.55 kW motor at 230 V, making it suitable for standard workshop installations.
- Precision spindle: Guaranteed concentricity less than 0.03 mm.
- Flexible drilling table: Can be tilted ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium lever arm and heavy base plate with T-slots.
- Variable speed: 12-step gearbox with range from 300 to 2300 min⁻¹.
- Safe operation: Separate emergency stop and 24 V DC safety voltage.
Pros and cons
- High precision and stability during drilling
- Adjustable drilling table with great freedom of movement
- Robust aluminium and steel construction
- Wide speed range with 12 steps
- Suitable for precision work in metal
- The relatively high weight of approximately 42 kg can make moving difficult
- Requires a fixed workstation and proper setup for optimal stability
Pros and cons
Pros
- High precision and stability during drilling
- Adjustable drilling table with great freedom of movement
- Robust aluminium and steel construction
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- The relatively high weight of approximately 42 kg can make moving difficult
- Requires a fixed workstation and proper setup for optimal stability
Pros
- High precision and stability during drilling
- Adjustable drilling table with great freedom of movement
- Robust aluminium and steel construction
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- The relatively high weight of approximately 42 kg can make moving difficult
- Requires a fixed workstation and proper setup for optimal stability
Specifications
- Model: OPTIdrill DQ 22
- Supply voltage: 230 V
- Power: 0.55 kW
- Mains frequency: 50 Hz
- Speed range: 300–2300 min⁻¹ (12 steps)
- Column diameter: 70 mm
- Drilling capacity in steel (S235JR): 20 mm
- Continuous drilling capacity in steel (S235JR): 16 mm
- Drilling table: 270 × 270 mm, 14 mm T-slot, 2 slots, 360° rotation, ±45° angle
- Maximum distance spindle – drilling table: 460 mm
- Maximum distance spindle – machine base: 639 mm
- Spindle taper: MK 2
- Spindle travel: 85 mm
- Throat depth: 169 mm
- Dimensions (L×W×H): approx. 700 × 351 × 1006 mm
- Weight: approx. 41.7 kg
- Drilling table load capacity: 15 kg
The Proxxon TBM 220 is a small but powerful bench drill designed for precision work. It can drill holes down to 0.5 mm, making it suitable for tasks where accuracy and control are more important than brute power.
The machine is equipped with a milled flat worktable made of die-cast aluminium, measuring 220 x 120 mm, providing a stable and flat surface. The table has both a parallel stop and a scale, making precise work with repeated drilling easier.
The hard-chromed steel column, measuring 20 x 280 mm, ensures stability, while the die-cast aluminium arm with precise guides contributes to a rigid, low-vibration construction.
The TBM 220 is powered by a quiet and durable VDE-tested motor with a three-step belt drive, offering three different speeds: 1,800, 4,700, and 8,500 revolutions per minute. By changing the belt, the user can choose between high speed for small drills and lower speed with increased torque for larger drills.
The machine has a quill stroke of 30 mm and a throat depth of 140 mm (distance from the centre of the column to the centre of the drill). It is supplied with six MICROMOT collets in sizes 1.0 – 3.2 mm, as well as a thread for mounting a keyed chuck.
- Precision drilling: Can drill holes down to 0.5 mm in diameter.
- Three-step belt drive: Offers three speeds – 1,800, 4,700, and 8,500 rpm.
- Stable construction: Milled flat worktable and hard-chromed steel column ensure accuracy.
- Quality motor: VDE-tested motor with low noise level and long service life.
- Included collets: Six MICROMOT collets from 1.0 to 3.2 mm.
Pros and cons
- High precision and stability for small drilling tasks
- Three speed levels adapted to different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros and cons
Pros
- High precision and stability for small drilling tasks
- Three speed levels adapted to different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros
- High precision and stability for small drilling tasks
- Three speed levels adapted to different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Specifications
- Model: TBM 220
- Item number (SKU): ROL-28128
- Voltage: 220–240 V
- Power: 85 W
- Frequency: 50–60 Hz
- Speed: 1,800 / 4,700 / 8,500 rpm
- Throat depth: 140 mm
- Quill stroke: 30 mm
- Worktable: 220 x 120 mm, milled flat die-cast aluminium
- Column: 20 x 280 mm, hard-chromed steel
- Collets: 6 pcs. MICROMOT (1.0 – 3.2 mm)
- Thread for chuck: 3/8"
- EAN / Barcode: ROL-28128
The Axminster Professional AP20BD is a bench drill designed to deliver precise results and stable operation in workshop environments. The machine is equipped with a precision spindle that runs in NSK ball bearings, reducing vibrations and ensuring smooth rotation during drilling.
The drive system uses Multi-V belts, which provide good grip and contribute to quiet and stable operation. The spindle unit is solidly integrated into the machine head, increasing the overall rigidity and precision of the machine.
Safety is a priority, with an electrically interlocked chuck guard that prevents accidental start-up, as well as a safety switch that cuts power when the belt cover is open. An integrated LED work light provides good illumination of the work area.
The machine has an ergonomic cast iron handle with a rubber grip for comfortable operation. The keyless chuck allows quick drill bit changes, and the table can be adjusted via rack and pinion. An improved depth stop allows drilling with high precision.
Thanks to its compact dimensions and solid construction, the AP20BD is suitable for both professional workshops and demanding hobby users who want a stable and precise bench drill.
- Precision spindle with NSK bearings: Provides stable and vibration-free drilling.
- Multi-V belt drive: Ensures smooth power transmission and low noise level.
- Safety switches: Prevent operation with the cover open or without protection.
- LED work light: Improves visibility during work.
- Ergonomic design: Cast iron handle with rubber grip for comfortable operation.
- Keyless chuck: Quick and easy drill bit change.
Pros and cons
- Robust construction with high precision
- Reduced vibrations and stable operation
- Safety switches and protection against accidental start-up
- Easy adjustment of table and drilling depth
- Built-in LED light for better illumination of the work area
- The relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient room
- Speed adjustment is done manually via pulleys
Pros and cons
Pros
- Robust construction with high precision
- Reduced vibrations and stable operation
- Safety switches and protection against accidental start-up
- Easy adjustment of table and drilling depth
- Built-in LED light for better illumination of the work area
Cons
- The relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient room
- Speed adjustment is done manually via pulleys
Pros
- Robust construction with high precision
- Reduced vibrations and stable operation
- Safety switches and protection against accidental start-up
- Easy adjustment of table and drilling depth
- Built-in LED light for better illumination of the work area
Cons
- The relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient room
- Speed adjustment is done manually via pulleys
Specifications
- Model: AP20BD
- Voltage: 230 V
- Power: 750 W
- Speed range: 120 – 2,580 rpm
- Chuck capacity: 1 – 16 mm (keyless)
- Spindle travel: 80 mm
- Morse taper: 2 MT
- Spindle taper: 2 MT
- Column diameter: 80 mm
- Maximum drilling in mild steel: 20 mm
- Maximum distance chuck - base: 500 mm
- Maximum distance chuck - table: 325 mm
- Table size: 290 × 290 mm
- Table tilt: 45° – 0° – 45°
- Base size: 450 × 270 mm
- Throat depth: 178 mm
- Overall dimensions (L × W × H): 670 × 360 × 1,020 mm
- Net weight: 82 kg
- Plug type: EU 2-pin plug
- Classification: Craftsman/Professional
The PROMAC 212 bench drill is a stationary machine designed for precision work in metal and other hard materials. It is equipped with a single-speed motor and speed adjustment via a V-belt, providing stable operation and the ability to adapt the rotation speed to different drilling tasks.
The machine is supplied with a 16 mm self-tightening chuck, safety screen and emergency stop button, which enhance safety during use. The table is adjustable and has cross grooves, facilitating secure clamping of workpieces during drilling.
An integrated safety system prevents automatic restart after a power failure, contributing to a safer working process. Its compact size and weight of 45 kg make it suitable for both workshops and smaller production environments where a stable and precise drill is required.
- 16 mm drilling capacity: Suitable for drilling in steel and other metals.
- Speed adjustment via V-belt: Offers flexibility depending on the material and type of drilling.
- Self-tightening chuck: Quick and secure clamping of drill bits without using a key.
- Adjustable table with cross grooves: Allows precise positioning of workpieces.
- Safety system against automatic start-up: Increases safety during power interruptions.
Pros and cons
- Stable construction, suitable for workshop use
- Easy speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for a flexible working position
- Single motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust rotation speed
Pros and cons
Pros
- Stable construction, suitable for workshop use
- Easy speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for a flexible working position
Cons
- Single motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust rotation speed
Pros
- Stable construction, suitable for workshop use
- Easy speed adjustment via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for a flexible working position
Cons
- Single motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust rotation speed
Specifications
- Motor voltage: 230 V
- Motor power: 0.37 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 5 steps
- Speed range: 490–2510 min⁻¹
- Maximum table load: 30 kg
- T-slot: 12 mm
- Weight: 45 kg
- Dimensions (A–J): A: 970 mm, B: 560 mm, C: 640 mm, D: 168 mm, E: 73 mm, F: 40 mm, G: 445 mm, H: 320 mm, I: 265 mm, J: 265 mm
- Item number (SKU): 212
Other products
The Holzmann GBM25 400V is a stationary bench drill designed for demanding drilling tasks. The machine is equipped with a 400V motor with two speeds and a total power of 650/900 W, providing sufficient power for processing both metal and wood.
The drill head can rotate 360 degrees and be adjusted in height, offering great flexibility for different work tasks. The robust and vibration-free construction ensures precise results, even during prolonged use.
The machine has eight different speeds, allowing the drilling speed to be adjusted according to the material. The table is equipped with T-slots and a T-stop, providing stable clamping of workpieces during operation.
With a maximum drilling capacity of 25 mm and threading up to M10, the GBM25 400V is suitable for both professional users and advanced hobbyists who want a reliable and powerful drill for workshop use.
- Powerful motor: two-speed motor of 650/900 W with operating voltage of 400V.
- Flexible drilling unit: The drill head can rotate 360° and be adjusted in height.
- Precision work: Vibration-free construction and solid base for stable drilling.
- Variable speed: 8 speeds adapted to different materials.
- High drilling capacity: Drilling diameter up to 25 mm and threading up to M10.
Pros and cons
- Robust and vibration-free construction
- Two-speed motor with high power
- 360° rotating and height-adjustable drill head
- Multiple speed settings for precise control
- Suitable for processing both metal and wood
- Requires 400V power supply, which limits use in ordinary households
- Relatively heavy and stationary – not suitable for mobile use
Pros and cons
Pros
- Robust and vibration-free construction
- Two-speed motor with high power
- 360° rotating and height-adjustable drill head
- Multiple speed settings for precise control
- Suitable for processing both metal and wood
Cons
- Requires 400V power supply, which limits use in ordinary households
- Relatively heavy and stationary – not suitable for mobile use
Pros
- Robust and vibration-free construction
- Two-speed motor with high power
- 360° rotating and height-adjustable drill head
- Multiple speed settings for precise control
- Suitable for processing both metal and wood
Cons
- Requires 400V power supply, which limits use in ordinary households
- Relatively heavy and stationary – not suitable for mobile use
Specifications
- Motor power (S1): 650/900 W
- Voltage: 400V
- Working distance: 255 mm
- Table size: 500 × 350 mm
- Spindle taper: MK3/MT3
- Maximum drilling capacity: 25 mm
- Maximum thread size: M10
- Quill stroke: 120 mm
- Column diameter: 100 mm
- Base: 500 × 400 mm
- T-slots: 14 mm
The Optimum OPTIdrill DQ 18 is a bench drill designed for precision drilling in metal and other hard materials. The machine is equipped with a precision spindle with ball bearings and a high-quality quick-action chuck, ensuring stable operation and precise results.
The drilling table is made of robust material and can be tilted ±45° and rotated 360°, providing flexibility for various drilling tasks. The table has diagonally arranged T-slots and a cooling channel around it, making it suitable for precision work and efficient cooling.
The machine is powered by a 0.45 kW motor with five speed levels, ranging from 600 to 2400 revolutions per minute. It is equipped with a GATES quality belt for stable power transmission and reduced vibrations during operation.
Safety is a priority, with a separate emergency stop switch and low-voltage control at 24 V DC. The solid column and base plate with T-slots provide the machine with a stable base, while the die-cast aluminium feed lever with soft grip ensures comfortable operation.
- Precision spindle: Ball bearings and concentricity accuracy below 0.03 mm.
- Adjustable drilling table: Can be tilted ±45° and rotated 360° for flexible machining.
- Stable construction: Strong column and ribbed base plate with T-slots.
- Safe operation: Separate emergency stop and 24 V DC safety voltage.
- Variable speed: Five speed levels from 600 to 2400 revolutions per minute.
Pros and cons
- High precision and stable operation
- Flexible drilling table with tilt and rotation
- Solid construction with quality components
- Safety features with emergency stop and low voltage
- Suitable for both metal and wood processing
- Relatively heavy construction of approximately 28.5 kg may require a fixed workspace
- Manual speed adjustment via pulleys
Pros and cons
Pros
- High precision and stable operation
- Flexible drilling table with tilt and rotation
- Solid construction with quality components
- Safety features with emergency stop and low voltage
- Suitable for both metal and wood processing
Cons
- Relatively heavy construction of approximately 28.5 kg may require a fixed workspace
- Manual speed adjustment via pulleys
Pros
- High precision and stable operation
- Flexible drilling table with tilt and rotation
- Solid construction with quality components
- Safety features with emergency stop and low voltage
- Suitable for both metal and wood processing
Cons
- Relatively heavy construction of approximately 28.5 kg may require a fixed workspace
- Manual speed adjustment via pulleys
Specifications
- Manufacturer: Optimum
- Model: OPTIdrill DQ 18
- SKU: SM-3191042
- Column diameter: 60 mm
- Length: approx. 568 mm
- Width/depth: approx. 319 mm
- Height: approx. 849 mm
- Weight: approx. 28.5 kg
- Drilling capacity steel (S235JR): 15.9 mm
- Continuous drilling capacity steel (S235JR): 14 mm
- Drilling table size: 200 × 200 mm
- T-slot size: 14 mm (2 pcs., diagonal type)
- Rotation: 360°
- Angle: ±45°
- Load capacity: 12 kg
- Maximum distance spindle – drilling table: 319 mm
- Drive motor power: 0.45 kW
- Supply voltage: 230 V
- Mains frequency: 50 Hz
- Maximum distance spindle – machine base: 518 mm
- Speed range: 600–2400 min⁻¹ (5 levels)
- Spindle chuck: MK 2
- Feed stroke: 65 mm
- Working depth: 127 mm
The Axminster Professional AP340PD is a compact bench drill that combines many of the features of larger models in a space-saving design. It is built from cast iron to ensure stability and vibration damping during use.
The machine is powered by a 550 W induction motor, which provides smooth operation and low noise levels. It offers 12 belt speeds from 210 to 2,580 revolutions per minute, making it suitable for various drilling tasks in both wood and metal.
The chuck is keyless and has a range from 1 to 16 mm, mounted on a 2MT spindle. The table can be adjusted in height via rack and pinion and can be rotated to allow the use of the machine base as a work support.
Safety is a priority, with an electrically interlocked chuck guard, a safety switch on the belt cover and an emergency stop function on the on/off switch. An integrated LED work light provides better visibility during operation.
The machine is suitable for professional workshops, educational institutions and users who want a precise and solid drill for stationary use.
- Cast iron construction: Provides high stability and reduces vibrations.
- 12 belt speeds: From 210 to 2,580 rpm for flexible drilling control.
- Keyless chuck: 1–16 mm capacity mounted on 2MT spindle.
- Safety switches: Prevent operation with the belt cover open and protect the user.
- LED work light: Improves visibility during precision work.
- Adjustable table: Height adjustment via rack and pinion, can be rotated for larger workpieces.
Pros and cons
- Solid cast iron construction that dampens vibrations
- Wide speed range with 12 steps
- Keyless chuck for quick tool changes
- Integrated LED light and emergency stop for increased safety
- Suitable for both professional and educational environments
- Relatively heavy 63 kg construction requires a fixed placement
- Not suitable for use with mortising attachments
- Supplied with a UK-type plug, which may require an adapter
Pros and cons
Pros
- Solid cast iron construction that dampens vibrations
- Wide speed range with 12 steps
- Keyless chuck for quick tool changes
- Integrated LED light and emergency stop for increased safety
- Suitable for both professional and educational environments
Cons
- Relatively heavy 63 kg construction requires a fixed placement
- Not suitable for use with mortising attachments
- Supplied with a UK-type plug, which may require an adapter
Pros
- Solid cast iron construction that dampens vibrations
- Wide speed range with 12 steps
- Keyless chuck for quick tool changes
- Integrated LED light and emergency stop for increased safety
- Suitable for both professional and educational environments
Cons
- Relatively heavy 63 kg construction requires a fixed placement
- Not suitable for use with mortising attachments
- Supplied with a UK-type plug, which may require an adapter
Specifications
- Model: AP340PD
- Item number (SKU): AX107704
- Spindle distance: 420 mm x 250 mm
- Chuck: 1–16 mm keyless
- Column diameter: 70 mm
- Maximum distance from chuck to spindle: 530 mm
- Maximum distance from chuck to table: 340 mm
- Maximum drilling capacity in mild steel: 16 mm
- Morse taper: 2 MT
- Spindle taper: 2 MT
- Power: 550 W induction motor
- Speed: 210–2,580 rpm (12 steps)
- Table size: 260 mm x 260 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 165 mm
- Voltage: 230 V
- Weight: 63 kg
- Dimensions (L x W x H): 640 x 370 x 1,000 mm
- Plug type: UK 3-pin plug
- User level: commercial/professional use
The PROMAC Bench Drill JDT-2512V is a stationary machine designed for precision drilling in metal and other hard materials. It is made of cast iron, which provides high stability and reduces vibrations during operation.
The machine has a drilling capacity of up to 23 mm in mild steel and a spindle speed that can be continuously adjusted in the range of 100–2100 revolutions per minute. This allows the speed to be adapted to different materials and drilling tasks.
The worktable can be tilted ±45° and has a load capacity of 60 kg, providing flexibility for angled drilling. The table and base are made of cast iron to ensure a solid working surface.
With a spindle travel of 100 mm, a column diameter of 70 mm and a total height of 1040 mm, the machine is suitable for both small and medium-sized workpieces. It is equipped with an MT-2 spindle taper and a B16 chuck with a capacity from 1–16 mm.
- Variable speed: Adjustable spindle speed from 100 to 2100 rpm.
- Stable construction: Cast iron head, table and base for maximum stability.
- High drilling capacity: Up to 23 mm in mild steel.
- Flexible worktable: Can be tilted ±45° and supports up to 60 kg.
- Precision spindle: MT-2 taper and 100 mm spindle travel for precise drilling.
Pros and cons
- Robust cast iron construction that dampens vibrations
- Variable speed adapted to different materials
- High drilling capacity and precise spindle guidance
- Flexible worktable with tilting function
- The relatively high weight of 91 kg may limit mobility
- Requires a fixed workspace and proper installation for optimal use
Pros and cons
Pros
- Robust cast iron construction that dampens vibrations
- Variable speed adapted to different materials
- High drilling capacity and precise spindle guidance
- Flexible worktable with tilting function
Cons
- The relatively high weight of 91 kg may limit mobility
- Requires a fixed workspace and proper installation for optimal use
Pros
- Robust cast iron construction that dampens vibrations
- Variable speed adapted to different materials
- High drilling capacity and precise spindle guidance
- Flexible worktable with tilting function
Cons
- The relatively high weight of 91 kg may limit mobility
- Requires a fixed workspace and proper installation for optimal use
Specifications
- Model: JDT-2512V
- Drilling capacity (mild steel): 23 mm
- Tapping capacity (mild steel): M14
- Chuck size: B16 (1–16 mm)
- Spindle travel: 100 mm
- Distance chuck to base: 500 mm
- Distance chuck to table (max): 255 mm
- Table size: 246 × 278 mm
- Table travel: 224 mm
- Table tilt: ±45°
- Table load capacity: 60 kg
- Head travel: 345 mm
- Spindle taper: MT-2
- Column diameter: Ø70 mm
- Spindle speed range: 100–2100 rpm
- Pulley material: Cast iron
- Base size: 340 × 520 mm
- Base working surface: 258 × 275 mm
- Material (table, base, head): Cast iron
- Distance spindle to column: 203 mm
- Overall dimensions (L×W×H): 690 × 410 × 1040 mm
- Net weight: 91 kg
The Holzmann SB4115N 230V is a stable bench drill designed for precision work in wood and metal. The machine is built with a solid, brushed column that ensures stability during drilling and has a worktable that can tilt 45 degrees on each side and rotate 360 degrees for flexible positioning.
The motor is made of aluminium and has IP54 protection, offering a robust and reliable construction. A transparent cover protects the chuck, while the handle with integrated depth scale allows for high-precision drilling.
The machine comes with a self-tightening chuck and has a maximum drilling capacity of 16 mm. The variable spindle speed ranges between 200 and 2500 revolutions per minute, making it suitable for various materials and drilling tasks.
With a net weight of 30 kg and compact dimensions, the SB4115N 230V is a practical solution both for smaller workshops and for hobby users who want a stable and versatile drill.
- Solid construction: The brushed column and stable base ensure precise drilling operations.
- Tilting worktable: Can be tilted +45°/-45° and rotated 360° for flexible use.
- Aluminium motor IP54: Provides reliability and protection against dust and moisture.
- Precise depth scale: Handle with integrated measuring scale for precise drilling.
- Variable speed: 12 steps from 200 to 2500 revolutions per minute.
Pros and cons
- Robust and stable construction
- Flexible worktable with tilt and rotation function
- Includes self-tightening chuck
- Precise depth scale for controlled drilling
- Suitable for both wood and metal
- Relatively heavy compared to smaller hobby drills
- Requires a fixed workspace due to its weight and size
Pros and cons
Pros
- Robust and stable construction
- Flexible worktable with tilt and rotation function
- Includes self-tightening chuck
- Precise depth scale for controlled drilling
- Suitable for both wood and metal
Cons
- Relatively heavy compared to smaller hobby drills
- Requires a fixed workspace due to its weight and size
Pros
- Robust and stable construction
- Flexible worktable with tilt and rotation function
- Includes self-tightening chuck
- Precise depth scale for controlled drilling
- Suitable for both wood and metal
Cons
- Relatively heavy compared to smaller hobby drills
- Requires a fixed workspace due to its weight and size
Specifications
- Model: SB4115N-230V
- Motor power S1/S6: 400 W / 600 W
- Voltage: 230 V
- Table dimensions: 200 × 200 mm
- Maximum height: 850 mm
- Distance from chuck to column: 127 mm
- Machine dimensions (without long table): 550 × 370 × 550 mm
- Maximum stroke: 60 mm
- Base plate: 350 × 210 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 steps, 200–2500 min⁻¹
- Distance from spindle to base plate: 525 mm
- Distance between spindle and table: 360 mm
- Net weight: 30 kg
- Package dimensions (L×W×H): 690 × 430 × 260 mm
The Holzmann SB4116HM 400V is a stable bench drill designed for precision work. It has a solid, polished base with T-slots, providing a secure foundation during drilling.
The machine is powered by an aluminium motor with IP54 protection, making it resistant to dust and moisture. The column is made of polished stainless steel, contributing to both strength and durability.
The worktable can tilt from -45° to +45° and rotate 360° around its centre, offering great flexibility for various drilling tasks. A protective cover around the spindle increases safety during use.
Delivery includes a self-tightening chuck (3–16 mm, B16), so the machine is ready for use immediately after delivery.
- Powerful motor: 600 W (S1) / 900 W (S6) with operating voltage of 400 V.
- Flexible worktable: Can tilt from -45° to +45° and rotate 360°.
- Robust construction: Stainless steel column and solid base with T-slots.
- Safety: Protective cover around the spindle.
- Precision: Maximum drilling capacity of 16 mm and 12 speed levels from 180 to 2740 revolutions per minute.
Pros and cons
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable for flexible drilling
- Powerful motor with multiple speed levels
- Comes with a self-tightening chuck
- Requires 400 V power supply, which is not available in all workshops
- Weight of 50 kg makes it less mobile
Pros and cons
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable for flexible drilling
- Powerful motor with multiple speed levels
- Comes with a self-tightening chuck
Cons
- Requires 400 V power supply, which is not available in all workshops
- Weight of 50 kg makes it less mobile
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable for flexible drilling
- Powerful motor with multiple speed levels
- Comes with a self-tightening chuck
Cons
- Requires 400 V power supply, which is not available in all workshops
- Weight of 50 kg makes it less mobile
Specifications
- Model: SB4116HM-400V
- Motor power (S1/S6): 600 W / 900 W
- Voltage: 400 V
- Table dimensions: 250 × 250 mm
- Maximum height: 1060 mm
- Distance from chuck to column: 170 mm
- Maximum stroke: 80 mm
- Base plate: 270 × 450 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 levels, 180–2740 min⁻¹
- Distance from spindle to base plate: 695 mm
- Maximum distance between spindle and table: 495 mm
- Net weight: 50 kg
- Package dimensions (L×W×H): 895 × 490 × 290 mm
- Delivery contents: Self-tightening chuck 3–16 mm, B16
The Holzmann SB4115N 400V is a stationary bench drill designed to provide stable and precise drilling. The machine is built with a solid, brushed column that ensures rigidity during operation and an aluminium motor with IP54 protection, contributing to reliability and long service life.
The worktable can rotate 360 degrees and tilt from +45 to -45 degrees, offering flexibility when drilling at different angles. An integrated depth scale on the handle allows precise control of drilling depth.
The machine comes with a self-tightening drill chuck and has a maximum drilling capacity of 16 mm. The spindle speed can be adjusted in 12 steps from 200 to 2500 revolutions per minute, allowing adaptation to different materials and drilling tasks.
With a maximum height of 850 mm and a net weight of 30 kg, the SB4115N 400V is a compact yet stable machine, suitable for both smaller workshops and hobby users who want precision and reliability in their drilling work.
- Solid construction: The strong column and base ensure stability during drilling.
- Adjustable worktable: Can rotate 360° and tilt ±45° for flexible use.
- Aluminium motor IP54: Provides reliability and protection against dust and moisture.
- Depth scale: Allows precise control of drilling depth.
- Variable speed: 12 steps from 200 to 2500 revolutions per minute.
Pros and cons
- Stable and robust construction
- Flexible worktable with tilt and rotation function
- Self-tightening chuck included
- Option for precise depth control
- Suitable for both metal and wood work
- Relatively heavy for transport and moving
- Requires a fixed workspace for optimal stability
Pros and cons
Pros
- Stable and robust construction
- Flexible worktable with tilt and rotation function
- Self-tightening chuck included
- Option for precise depth control
- Suitable for both metal and wood work
Cons
- Relatively heavy for transport and moving
- Requires a fixed workspace for optimal stability
Pros
- Stable and robust construction
- Flexible worktable with tilt and rotation function
- Self-tightening chuck included
- Option for precise depth control
- Suitable for both metal and wood work
Cons
- Relatively heavy for transport and moving
- Requires a fixed workspace for optimal stability
Specifications
- Model: SB4115N 400V
- Motor power S1 / S6: 400 W / 600 W
- Voltage: 230 V
- Table dimensions: 193 × 200 mm
- Maximum height: 850 mm
- Distance from chuck to column: 127 mm
- Maximum stroke: 60 mm
- Base plate: 350 × 210 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 steps, 200–2500 min⁻¹
- Distance from spindle to base plate: 525 mm
- Maximum distance between spindle and table: 360 mm
- Net weight: 30 kg
- Package dimensions (L × W × H): 690 × 430 × 260 mm
- Delivery contents: Self-tightening chuck
The Holzmann GBM25T 400V is a stationary bench drill designed for demanding drilling tasks. The machine is equipped with gears, allowing the user to control drilling with high precision and adjust the speed according to the material.
The solid, vibration-free construction ensures stable operation, while the integrated T-slot guide in the table provides good support during work. The drill head can rotate 360 degrees and can be adjusted in height, making the machine flexible in use.
The GBM25T has eight different speeds and two powerful motor stages, making it suitable for both fine drilling and more demanding tasks. The combination of robust design and adjustable features makes it a versatile tool in professional and semi-professional workshops.
- Powerful motor: 650/900 W motor operating at 400V ensures high performance.
- Precise drilling control: The gear system and 8 speeds offer flexibility in work.
- 360° rotating drill head: Allows drilling from multiple angles.
- Solid construction: Robust and vibration-free construction for stable operation.
- Adjustable table: Table with T-slot guide and adjustable height for precise positioning.
Pros and cons
- Strong and stable construction
- Possibility of precise speed adjustment
- Rotating and height-adjustable drill head
- Suitable for both metal and wood work
- Requires 400V power supply
- Relatively heavy and stationary – not suitable for mobile use
Pros and cons
Pros
- Strong and stable construction
- Possibility of precise speed adjustment
- Rotating and height-adjustable drill head
- Suitable for both metal and wood work
Cons
- Requires 400V power supply
- Relatively heavy and stationary – not suitable for mobile use
Pros
- Strong and stable construction
- Possibility of precise speed adjustment
- Rotating and height-adjustable drill head
- Suitable for both metal and wood work
Cons
- Requires 400V power supply
- Relatively heavy and stationary – not suitable for mobile use
Specifications
- Motor power (S1): 650/900 W
- Voltage: 400V
- Working distance: 255 mm
- Table size: 250 × 290 mm
- Taper: MK3/MT3
- Maximum drilling capacity: 25 mm
- Maximum thread size: M10
- Spindle travel: 120 mm
- Speed range: 105–2900 min⁻¹
- Column diameter: 100 mm
- Base: 570 × 340 mm
- T-slots: 14 mm
Different types of bench drills
There are several types of bench drills that vary in size, function and field of application. The choice depends on how much space you have and the materials you work with.
1. Standard bench drills
These compact models are ideal for hobby workshops and smaller projects. They usually have moderate motor power and a simple adjustable table. They are easy to place on a workbench and require minimal maintenance.
2. Pillar drills
Pillar drills are larger and more powerful than standard models. They stand on the floor and allow drilling of larger workpieces. They are suitable for professional workshops and demanding tasks where precision and power are essential.
3. Magnetic drills
Magnetic drills are mainly used for metalworking. They can be attached to steel surfaces using an electromagnet, making them ideal for precise drilling in steel structures and pipes. They are often more expensive but very flexible.
4. CNC-controlled bench drills
The most advanced models can be digitally programmed and used for series production or complex drilling tasks. They are usually reserved for professional users who require high precision and consistent repeatability.
Different brands of bench drills
The bench drill market includes many manufacturers, each with their own areas of specialisation and strengths.
Bosch
Bosch offers a wide range of bench drills for both hobby and professional use. The machines are known for their high build quality, ease of use and precision. Most models have continuous speed adjustment and a solid construction.
Einhell
Einhell produces affordable machines aimed at DIY users. They are easy to operate and suitable for general drilling tasks in wood and metal. The brand is popular for its combination of price and functionality.
Scheppach
Scheppach is known for robust machines with good performance for the price. Their bench drills often have powerful motors and stable tables, making them suitable for both hobby and semi-professional use.
Metabo
Metabo focuses on professional quality and durability. Their machines have high precision, powerful motors and advanced safety features. They are an obvious choice for workshops where the machine is used frequently.
Holzmann
Holzmann offers a wide range of bench drills, from compact models to large pillar machines. The brand is known for its solid construction and good balance between price and quality.
Frequently asked questions
What can a bench drill be used for?
A bench drill is used to make precise and straight holes in wood, metal, plastic and other materials. It is ideal for repetitive drilling tasks where portable drills do not offer enough precision.
How big should a bench drill be?
It depends on the materials and workpieces you are working with. For small hobby projects, a compact model is often sufficient, while larger and more powerful machines are needed for metalworking or large wooden pieces.
How do you maintain a bench drill?
Keep the machine clean from dust and chips, regularly lubricate moving parts and check belts and bearings for wear. Make sure the chuck and drilling table are properly adjusted to maintain precision.
Are bench drills safe to use?
Yes, if used correctly. Always wear safety glasses and make sure the workpiece is securely fixed. Choose a machine with a protective screen and emergency stop for extra protection.
Can a bench drill drill metal?
Yes, most models can drill metal, but a suitable drill bit and appropriate speed are required. Use cutting oil to reduce heat build-up and extend the drill bit’s lifespan.
Læs også:
